⚙️ Working Process

1️⃣ Hard Water Inlet
Water enters the system containing hardness-causing ions like calcium and magnesium.

2️⃣ Ion Exchange Resin
Water passes through a bed of cation exchange resin, which traps hardness ions and replaces them with sodium ions.

3️⃣ Soft Water Output
The result is soft water with reduced scaling potential, ideal for use in industrial and domestic systems.

4️⃣ Regeneration Cycle
Once the resin is saturated, the system uses brine solution (NaCl) to regenerate the resin bed, making it ready for the next cycle.

🧪 Technical Specifications

• Treatment Capacity: 500 LPH to 25,000 LPH

• Resin Type: Strong Acid Cation Resin

• Hardness Removal: Calcium & Magnesium

• Regeneration Method: Common Salt (NaCl)

• Output Water Hardness: <5 ppm (Commercially Zero)

• Operating Pressure: Up to 3.5 kg/cm²

• Material: FRP, MSRL or SS Skid-mounted options available

🏭 Applications

✔️ Boiler Feed Water Treatment
✔️ Cooling Tower Make-up Water
✔️ Pharmaceutical & Chemical Units
✔️ Textile and Dyeing Industries
✔️ Food and Beverage Processing
✔️ Hotels, Hospitals, Educational Institutions
✔️ Domestic Water Softening Solutions

🌍 Why Choose Aqua Globe?

✅ Top WSP Plant Manufacturer in Punjab, HP & J&K
✅ Zero Hardness Output – Maximum Equipment Life
✅ Simple Operation & Low Maintenance
✅ Custom Built for Small to Large Water Demands
✅ Trusted by Industrial, Institutional, and Commercial Sectors
✅ Regeneration with Common Salt – Cost-effective Solution
